T type Lifting Anchor

ANCHOR LIFTING SYSTEM

Material: Cold Rolled Steel / 20# Steel
Surface Treatment: Galvanized
Alloy or Not: Non-Alloy
Thread Type: Rd12 - Rd52
Packaging: Carton Box on Pallets
Lead Time: 15-45 days
Delivery Time: 22-30 days
Warranty: 1-3 Years
Customized Support: OEM Available
Supply Ability: Up to 20 Tons per Month
Application: Precast Concrete Accessories
Place of Origin: China (Shandong)
Port: Qingdao

Inquire Now >>

Product Detail

Spherical Head Anhcor is forged from round steel.Suitable for large precast concrete elements, such as

pipes,slabs,beams,panels.The anchor head is clearly marked with SWL.Anchors in the same load group are available in

various lengths. Longer anchors are installed for reduced edge spacing or for low concrete strengths.The load on the anchor

is transferred to the concrete through the anchor foot.The anchors must be fixed in the mould using recess formers.

The specification table shows standard anchor sizes and safe working loads in various concrete strengths.Note that in some

cases the anchor does not reach full capacity in the lower strength concretes. It is important to use it properly.In general,

concrete strengths from 2100 psi to 3500 psi are necessary to develop stated anchor safe working loads.

About JOYO

Qingdao Huazhuo HD Machinery Co., Ltd (JOYO), established in 1998, specializes in manufacturing high-quality precast concrete accessories, rigging hardware, and lifting tools. With over 60 years of experience through our parent company, Shandong Machinery I&E Group, we ensure strict quality control and excellent customer service.

Our products, certified by ISO 9001, SGS, and CE, are exported to over 120 countries. We partner with SGS for inspections and PICC for quality insurance, ensuring reliability. As a trusted one-stop service provider, we deliver comprehensive production and logistics solutions for precast concrete accessories.
